INVT Goodrive 35 Series Operation Manual page 340

inverters
Goodrive35
Model
GD35-022G-6-C1/D1/H1
GD35-030G-6-C1/D1/H1
GD35-037G-6-C1/D1/H1
GD35-045G-6-C1/D1/H1
GD35-055G-6-C1/D1/H1
GD35-075G-6-C1/D1/H1
GD35-090G-6-C1/D1/H1
GD35-110G-6-C1/D1/H1
GD35-132G-6-C1/D1/H1
GD35-160G-6-C1/D1/H1
GD35-185G-6-C1/D1/H1
GD35-200G-6-C1/D1/H1
GD35-220G-6-C1/D1/H1
GD35-250G-6-C1/D1/H1
GD35-280G-6-C1/D1/H1
GD35-315G-6-C1/D1/H1
GD35-350G-6-C1/D1/H1
GD35-400G-6-C1/D1/H1 DBU100H-400-6
GD35-500G-6-C1/D1/H1
GD35-560G-6-C1/D1/H1
GD35-630G-6-C1/D1/H1
Note:
Select the resistor and power of the braking unit according to the data our company
provided.
The braking resistor may increase the braking torque of the inverter. The resistor power in
the above table is designed on 100% braking torque and 10% braking usage ratio. If the
Braking
Resistor
Model of at 100%
braking of
unit the
braking
torque(Ω)
55
40.3
32.7
26.9
DBU100H-110-6
22.0
16.1
13.4
11.0
9.2
DBU100H-160-6
7.6
6.5
DBU100H-220-6 6.1
5.5
4.8
4.3
DBU100H-320-6
3.8
3.5
3.0
4.8*2
Two
4.3*2
DBU100H-320-6
3.8*2
339
www.barghmaher.ir
The consumed power of
the braking resistor
10% 50% 80%
braking braking braking
4 17 27
5 23 36
6 28 44
7 34 54
8 41 66
11 56 90
14 68 108
17 83 132
20 99 158
24 120 192
28 139 222
30 150 240
33 165 264
38 188 300
42 210 336
47 236 378
53 263 420
60 300 480
38*2 188*2 300*2
42*2 210*2 336*2
47*2 236*2 378*2
Appendix D
Min.
allowable
braking
resistance(Ω)
10.0
6.9
5.0
3.4
2.8
3.4*2
