INVT Goodrive 35 Series Operation Manual page 280

inverters
Goodrive35
Function Address
instruction definition
200AH
200BH
200CH
200DH
200EH
SW 1 of the
2100H
inverter
SW 2 of the
2101H
inverter
Data meaning instruction
=0: pre-exciting disabling
Bit5:=1 DC braking enabling
=0: DC braking disabling
Virtual input terminal command , range:
0x000~0x1FF
Virtual output terminal command , range:
0x00~0x0F
Voltage setting value(special for V/F
separation)
(0~1000, 1000 corresponds to the 100.0%)
AO output setting 1
(-1000~1000, 1000 corresponds to 100.0%)
AO output setting 2
(-1000~1000, 1000 corresponds to 100.0%)
0001H:forward running
0002H:forward running
0003H:stop
0004H:fault
0005H: POFF state
0006H: pre-exciting state
Bit0: =0:ready for operation =1:not ready for
operation
Bi1~2:=00:motor 1 =01:motor 2
=10:motor 3
Bit3: =0:asynchronous motor
=1:synchronous motor
Bit4:=0:pre-alarm without overload
=1:overload pre-alarm
Bit5~ Bit6: =00: keypad control =01: terminal
control
=10: communication control
279
www.barghmaher.ir
Communication protocol
=11:motor 4
R/W
characteristics
W/R
W/R
W/R
W/R
W/R
R
R
