Goodrive35
Function
code
P06.17 Lower output limit of AO1 -300.0%~P06.19
Corresponding AO1
P06.18
output of lower limit
P06.19 Upper output limit of AO1 P06.13~300.0%
The corresponding AO1
P06.20
output of upper limit
Detailed instruction of parameters
Name
the rated current of the inverter)
5:Output current(relative to 2 times of the
rated current of the motor)
6:Output voltage
7:Output power
8:Set torque value
9:Output torque
10:Analog AI1 input value
11:Analog AI2 input value
12:Analog AI3 input value
13:High speed pulse HDI input value
14:MODBUS communication set value 1
15:MODBUS communication set value 2
16:PROFIBUS/CANopen communication
set value 1
17:PROFIBUS/CANopen communication
set value 2
18: Ethernet communication set value 1
19: Ethernet communication set value 2
20~21: Reserved
22:Torque current(100% corresponds to
10V)
23:Pre-magnetizing current(100%
corresponds to 10V)
24: Setting frequency(bipolar)
25: Ramp reference frequency (bipolar)
26: Operation speed (bipolar)
0.00V~10.00V
0.00V~10.00V
210
www.barghmaher.ir
Basic operation instruction
Default
value
0.0%
0.00V
100.0%
10.00V
