inverters
Goodrive35
Function
Name
code
0~127
This function code is used to designate the address
of the inverter.
Module
P15.01
Note: 0 is the broadcast address, when set it as
address
broadcast address, only receive the radio command
of the upper monitor other than answering the upper
monitor.
PZD2
0:Invalid
P15.02
receiving
1:Setting frequency (0~Fmax(unit:0.01Hz))
2: PID reference, range (0~1000,1000 corresponds
PZD3
P15.03
to 100.0%)
receiving
3: PID feedback, range (0~1000,1000 corresponds
PZD4
P15.04
to 100.0%)
receiving
4:Torque setting (-3000~3000,1000 corresponds to
PZD5
P15.05
100.0% the rated current of the motor)
receiving
5:Upper frequency of forward rotation
PZD6
P15.06
(0~Fmax unit:0.01Hz))
receiving
6: Upper frequency of reverse rotation
PZD7
P15.07
(0~Fmax(unit:0.01Hz))
receiving
7:Electromotion torque upper limit (0~3000,1000
PZD8
P15.08
corresponds to 100.0%of the rated current of the
receiving
motor)
PZD9
P15.09
8:Braking torque upper limit (0~2000,1000
receiving
corresponds to 100.0% of the rated current of the
PZD10
P15.10
motor)
receiving
9:Virtual input terminals command
PZD11
P15.11
Range:0x000~0x1FF
receiving
10:Virtual output terminals command
Range:0x00~0x0F
11:Voltage setting value(special for V/F
PZD12
separation )(0~1000,1000 corresponds to 100.0%
P15.12
receiving
the rated voltage of the motor)
12: AO output set value 1(-1000~1000, 1000
corresponds to 100.0%)
Detailed instruction of parameters
146
www.barghmaher.ir
Function codes
Default
Modify
value
2
0
0
0
0
0
0
0
0
0
0
0
