Analog Input - INVT Goodrive 35 Series Operation Manual

Goodrive35 inverters
Function
code
UP terminals frequency
P08.45
changing ratio
DOWN terminals
P08.46
frequency changing ratio
P17.00 Setting frequency
P17.02 Ramp reference frequency
P17.14 Digital adjustment

7.9 Analog input

Goodrive35 series inverters have three analog input terminals and 1 high-speed pulse input terminals
(of which, AI1 and AI2 are 0 – 10 V/0 – 20mA and Al can select voltage input or current input by J3,
AI2 can select voltage input or current input by J4 and AI3 is for -10 – 10 V) as the standard
configuration. The inputs can be filtered and the maximum and minimum values can be adjusted.
Name
to the multi-step
LED hundreds: action selection when stop
0: Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving
the stop commands
0.01 – 50.00 Hz/s
0.01 – 50.00 Hz/s
Display current set frequency of the inverter
Range: 0.00 Hz – P00.03
Display current ramp given frequency of the
inverter
Range: 0.00 Hz – P00.03
Display the adjustment through the keypad of
the inverter.
Range : 0.00 Hz – P00.03
Detailed instruction of parameters
155
Basic operation instruction
Default
value
0.50 Hz/s
0.50 Hz/s
0.00 Hz
0.00 Hz
0.00 Hz
