INVT Goodrive 35 Series Operation Manual page 79

inverters
Goodrive35
Function
Name
code
frequency P03.15=1.
of forward
Setting range:0.00 Hz~P00.03 (the Max. output
rotation
frequency)
Keypad
setting for
upper
P03.17
frequency
of reverse
rotation
Upper This function code is used to select the
electromoti electromotion and braking torque upper-limit setting
P03.18
on torque source selection.
source 0:Keypad setting upper-limit frequency(P03.20 sets
P03.18, P03.21 sets P03.19)
1: AI1
2: AI2
3: AI3
Upper
4: HDI
braking
P03.19
torque
5:MODBUS communication
source
6:PROFIBUS/CANopen communication
7:Ethernet communication
Note: setting mode 1~7,100% corresponds to three
times of the motor current.
Keypad
setting of
P03.20
electromoti
on
The function code is used to set the limit of the
torque
torque.
Setting range:0.0~300.0%(motor rated current)
Keypad
setting of
P03.21
braking
torque
Detailed instruction of parameters
78
www.barghmaher.ir
Function codes
Default
Modify
value
50.00
○
Hz
○
0
○
0
180.0
○
%
180.0
○
%
