INVT Goodrive 35 Series Operation Manual page 88

inverters
Goodrive35
Function
Name
code
output The setting range of P04.31:P04.32~100.0%
voltage (the rated voltage of the motor)
The setting range of P04.32:0.0%~ P04.31
(the rated voltage of the motor)
Minimum
P04.32 output
voltage
P05 Group Input terminals
HDI input 0: High pulse input. See P05.49~P05.54
P05.00
selection 1: Digital input. See P05.09
S1
0: No function
terminals
1: Forward rotation operation
P05.01
function
2: Reverse rotation operation
selection
3: 3-wire control operation
S2
4: Forward jogging
terminals
5: Reverse jogging
P05.02
function
6: Coast to stop
selection
7: Fault reset
S3 8: Operation pause
terminals 9: External fault input
P05.03
function 10:Increasing frequency setting(UP)
selection 11:Decreasing frequency setting(DOWN)
12:Frequency setting clear
S4
13:Shift between A setting and B setting
terminals
P05.04
14:Shift between combination setting and A setting
function
15:Shift between combination setting and B setting
selection
16:Multi-step speed terminal 1
S5
17:Multi-step speed terminal 2
terminals
P05.05
18:Multi-step speed terminal 3
function
19:Multi- step speed terminal 4
selection
Detailed instruction of parameters
87
www.barghmaher.ir
Function codes
Default
Modify
value
%
◎
0.0%
◎
0
◎
1
◎
4
◎
7
◎
0
◎
0
