Reactors - INVT Goodrive 35 Series Operation Manual

inverters
Goodrive35
Model
GD35-022G-6-C1/D1/H1
GD35-030G-6-C1/D1/H1
GD35-037G-6-C1/D1/H1
GD35-045G-6-C1/D1/H1
GD35-055G-6-C1/D1/H1
GD35-075G-6-C1/D1/H1
GD35-090G-6-C1/D1/H1
GD35-110G-6-C1/D1/H1
GD35-132G-6-C1/D1/H1
GD35-160G-6-C1/D1/H1
GD35-185G-6-C1/D1/H1
GD35-200G-6-C1/D1/H1
GD35-220G-6-C1/D1/H1
GD35-250G-6-C1/D1/H1
GD35-280G-6-C1/D1/H1
GD35-315G-6-C1/D1/H1
GD35-350G-6-C1/D1/H1
GD35-400G-6-C1/D1/H1
GD35-500G-6-C1/D1/H1
GD35-560G-6-C1/D1/H1
GD35-630G-6-C1/D1/H1
Note: the specifications can be adjusted according to the actual working, but it can not be
less than the designated values.
D.6 Reactors
Transient high current in the input power circuit may cause damage to the rectifying parts. It
is appropriate to use AC reactor in the input side for the avoidance of high-voltage input of
the power supply and improvement of the power factors.
If the distance between the inverter and the motor is longer than 50m, frequent overcurrent
protection may occur to the inverter because of high leakage current caused by parasitic
capacitance effects from the long cables to the ground. In order to avoid the damage of the
