INVT Goodrive 35 Series Operation Manual page 155

inverters
Goodrive35
Function
Name
code
High bit of
the
The value will be cleared if stopping.
P18.03
position 0~30000
reference
Low bit of
the The value will be cleared if stopping.
P18.04
position 0~65535
reference
High bit of
the
The value will be cleared if stopping.
P18.05
position
0~30000
feedback
Low bit of
the
The value will be cleared if stopping.
P18.06
position
0~65535
feedback
The deviation between reference position and actual
Position
P18.07 operation position.
deviation
-32768~32767
Position
The reference position of Z pulse when spindle stops.
P18.08
reference
0~65535
Current
position of
Current position setting when spindle stops.
P18.09
the
0~359.99
spindle
Current
Current position of the spindle at the oriented spindle
position at
P18.10
stop.
spindle
0~65535
orientation
Detailed instruction of parameters
154
www.barghmaher.ir
Function codes
Default
Modify
value
●
0
●
0
●
0
●
0
●
0
●
0
●
0.00
●
0
