INVT Goodrive 35 Series Operation Manual page 282

inverters
Goodrive35
Function Address
instruction definition
stage of
multi-step speed
External length 3013H
External
3014H
counting
Torque setting 3015H
Identifying code
3016H
of the inverter
Fault code 5000H
R/W characteristics means the function is with read and write characteristics. For example,
"communication control command" is writing chrematistics and control the inverter with
writing command (06H). R characteristic can only read other than write and W characteristic
can only write other than read.
Note: when operate on the inverter with the table above, it is necessary to enable some
parameters. For example, the operation of running and stopping, it is necessary to set
P00.01 to communication running command channel and set P00.02 to MODBUS
communication channel. And when operate on "PID given", it is necessary to set P09.00 to
"MODBUS communication setting".
The encoding rules for device codes (corresponds to identifying code 2103H of the inverter)
High 8 bit Meaning
01 GD
10.4.5 Fieldbus ratio values
The communication data is expressed by hex in actual application and there is no radix point
in hex. For example, 50.12Hz can not be expressed by hex so 50.12 can be magnified by
100 times into 5012, so hex 1394H can be used to express 50.12.
A non-integer can be timed by a multiple to get an integer and the integer can be called
Data meaning instruction
0~65535
0~65535
-300.0~300.0% (unit: 0.1%)
Low 8 bit
0x08
0x09
0x0a
0x0b
0x0c
0x0d
0x0e
0x0f
281
www.barghmaher.ir
Communication protocol
characteristics
Meaning
GD35 vector inverter
GD35-H1 vector inverter
GD300 vector inverter
GD100 simple vector inverter
GD200 universal inverter
GD10 mini inverter
GD800 PWM rectifier
GD800 PWM inverter
R/W
R
R
R
R
R
