Goodrive300-19 series open loop vector inverter special for hosit
UP terminals
P08.45 frequency
changing ratio
DOWN
terminals
P08.46
frequency
changing ratio
Setting
P17.00
frequency
Ramp
P17.02 reference
frequency
Digital
P17.14
adjustment

7.9 Analog input

Goodrive300-19 series inverters have three analog input terminals and 1 high-speed pulse input
terminal (of which, AI1 and AI2 are 0~10V/0~20mA and Al can select voltage input or current input by
J3, AI2 can select voltage input or current input by J4 and AI3 is for -10~10V ) as the standard
configuration. The inputs can be filtered and the maximum and minimum values can be adjusted.
0: Setting is valid
1: Valid during running, clear after stop
2: Valid during running, clear after receiving the stop
command
0.01~50.00Hz/s
0.01~50.00Hz/s
0.00Hz~P00.03 (Max. output frequency)
0.00Hz~P00.03 (Max. output frequency)
0.00Hz~P00.03
-152-
Basic operation instruction
0.50Hz/s
0.50Hz/s
0.00Hz
0.00Hz
0.00Hz
