Canon iR2420 Trouble Error Codes List

Code
Startup error
E000-
The temperature detected by the main or
0000
sub thermistor does not rise to the
specified value during startup control.
Abnormally high temperature (detected by
main thermistor)
E001-
The main thermistor detected an
0000
abnormally high temperature (240 deg C)
during temperature control.
Abnormally high temperature (detected by
sub thermistor)
E001-
The sub thermistor detected an
0001
abnormally high temperature (295 deg C)
during temperature control.
Low temperature during temperature
E002-
control.
0000
The target temperature is not reached
during temperature control.
Abnormally low temperature (detected by
main thermistor)
E003-
After the temperature detected by the
0000
main thermistor has reached the specified
value, it does not reach the specified
value during initial rotation.
Abnormally low temperature (detected by
sub thermistor)
E003-
After the temperature detected by the sub
thermistor has reached the specified
0001
value, it does not reach the specified
value during initial rotation.
E007-
Fixing film sensor failure
0000
The fixing film sensor is faulty.
E010-
Main motor failure
0000
The main motor is faulty.
E019-
Waste toner full detection
0001
The waste toner full state was detected.
Waster toner full detection sensor is
E019-
faulty.
0002
The waste toner full state was detected
continuously for five or more seconds
Description
1
- Check the fixing film connector. - Replace
the fixing film unit. - Replace the DC
controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit. - Replace the
DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit. - Replace the
DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit. - Replace the
DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit. - Replace the
DC controller PCB.
- Check the connector of the fixing film unit.
- Replace the fixing film unit. - Replace the
DC controller PCB.
- Check the connector of the fixing film
sensor. - Replace the fixing film sensor. -
Replace the DC controller PCB.
- Check the connector of the main motor. -
Replace the main motor. - Replace the DC
controller PCB.
Replace the drum unit.
- Check the connector of the waster toner
full sensor. - Replace the waste toner full
sensor. - Replace the DC controller PCB.
Remedy
