Section 3: Functions and features

TSP-Link synchronization lines

The Series 2600B has three synchronization lines that you can use for triggering, digital I/O, and to
synchronize multiple instruments on a TSP-Link
The Models 2604B, 2614B, and 2634B do not have a TSP-Link
Connecting to the TSP-Link system
The TSP-Link
connectors located on the back of the Series 2600B. If you are using a TSP-Link network, you do not
have to modify any connections. See
detailed information about connecting to the TSP-Link system.
Using TSP-Link synchronization lines for digital I/O
Each synchronization line is an open-drain signal. When using the TSP-Link
for digital I/O, any node that sets the programmed line state to zero (0) causes all nodes to read 0
from the line state. This occurs regardless of the programmed line state of any other node. See the
table in the Digital I/O bit weighting
Remote TSP-Link synchronization line commands
Commands that control and access the TSP-Link
following table. See the
commands. See the table in
values used to control and access the digital I/O port and individual lines.
Use the commands in following table to perform basic steady-state digital I/O operations; for example,
you can program the Series 2600B to read and write to a specific TSP-Link synchronization line or to
the entire port.
The TSP-Link synchronization lines can be used for both input and output. You must write a 1 to all
TSP-Link synchronization lines that are used as inputs.
Remote synchronization line commands
Command
tsplink.readbit(bit)
tsplink.readport()
tsplink.writebit(bit, data)
tsplink.writeport(data)
tsplink.writeprotect = mask
3-90
®
synchronization lines are built into the TSP-Link connection. Use the TSP-Link
TSP-Link system expansion interface
(on page 3-86) topic for digital bit weight values.
TSP command reference
Digital I/O bit weighting
Series 2600B System SourceMeter® Instrument Reference Manual
®
network.
®
®
synchronization port are summarized in the
(on page 7-1) for complete details on these
(on page 3-86) for the decimal and hexadecimal
Description
Reads one digital I/O input line.
Reads the digital I/O port.
Writes data to one digital I/O line.
Writes data to the digital I/O port.
Sets write-protect mask of the digital I/O port.
interface.
(on page 6-47) for
®
synchronization lines
