Section 7: TSP command reference
Example
print(smua.nvbuffer1.readings[1])
Also see
bufferVar.measurefunctions
bufferVar.measureranges
bufferVar.n (on page 7-24)

bufferVar.sourcefunctions

bufferVar.sourceoutputstates
bufferVar.sourceranges
bufferVar.sourcevalues
bufferVar.statuses
bufferVar.timestamps
Reading buffers
bufferVar.sourcefunctions
This attribute contains the source function that was being used when the readings were stored in a specified
reading buffer.
Type TSP-Link accessible
Attribute (R) Yes
Usage
sourcefunction = bufferVar.sourcefunctions[N]
sourcefunction
bufferVar
N
Details
The sourcefunctions buffer recall attribute is like an array (a Lua table) of strings indicating the source
function at the time of the measurement.
For dedicated reading buffers, all buffer attributes are saved to nonvolatile memory only when the reading buffer
is saved to nonvolatile memory.
Example 1
sourcefunction = smua.nvbuffer1.sourcefunctions[3]
7-26
(on page 7-22)
(on page 7-23)
(on page 7-26)
(on page 7-27)
(on page 7-28)
(on page 7-29)
(on page 7-30)
(on page 7-32)
(on page 3-6)
Affected by
Clearing the buffer
The source function used ("current" or "voltage") to acquire reading number N
in the specified buffer
The reading buffer; can be a dynamically allocated buffer (user-defined), or a
dedicated reading buffer (such as smua.nvbuffer1)
The reading number (1 to bufferVar.n)
Series 2600B System SourceMeter® Instrument Reference Manual
Output the first reading saved in
source-measure unit (SMU) channel A,
dedicated reading buffer 1.
Output:
8.81658e-08
Where saved
See Details
Default value
Not applicable
Store the source function used
to make reading number 3.
2600BS-901-01 Rev. B / May 2013
