Section 7: TSP command reference
Usage
highC = smuX.source.highc
smuX.source.highc = highC
highC
X
Details
When enabled, the high-capacitance mode has the following effects on the SMU settings:
•
smuX.measure.autorangei is set to smuX.AUTORANGE_FOLLOW_LIMIT and cannot be changed
• Current ranges below 1 µA are not accessible
• If smuX.source.limiti is less than 1 µA, it is raised to 1 µA
• If smuX.source.rangei is less than 1 µA, it is raised to 1 µA
• If smuX.source.lowrangei is less than 1 µA, it is raised to 1 µA
• If smuX.measure.lowrangei is less than 1 µA, it is raised to 1 µA
Example
smua.source.highc = smua.ENABLE
Also see
High-capacitance mode

smuX.source.levelY

This attribute sets the source level.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
sourceLevel = smuX.source.levelY
smuX.source.levelY = sourceLevel
sourceLevel
X
Y
7-222
Series 2600B System SourceMeter® Instrument Reference Manual
The state of the high-capacitance mode; set to one of the following values:
0 or smuX.DISABLE: Disables high-capacitance mode
1 or smuX.ENABLE: Enables high-capacitance mode
Source-measure unit (SMU) channel (for example, smua.source.highc applies
to SMU channel A)
(on page 3-65)
Affected by
SMU reset
Instrument reset
Recall setup
The source value; set to one of the following values:
Voltage: 0 V to ±40 V (Models 2601B/2602B/2604B)
Voltage: 0 V to ±200 V (Models 2611B/2612B/2614B/2634B/2635B/2636B)
Current: 0 A to ±3 A (Models 2601B/2602B/2604B)
Current: 0 A to ±1.5 A (Models 2611B/2612B/2614B/2634B/2635B/2636B)
Source-measure unit (SMU) channel (for example, smua.source.levelv applies
to SMU channel A)
SMU source function (v = voltage, i = current)
Activates high-capacitance mode
for SMU channel A.
Where saved Default value
Saved setup 0
2600BS-901-01 Rev. B / May 2013
