Section 7: TSP command reference
Details
These attributes are used to read or write to the operation status remote summary registers. Reading a status
register returns a value. The binary equivalent of the returned value indicates which register bits are set. The
least significant bit of the binary number is bit B0, and the most significant bit is bit B15.
For information about .condition, .enable, .event, .ntr, and .ptr registers, refer to
page E-1) and
the following table.
Bit Value
B0 Not used
B1 status.operation.remote.COMMAND_AVAILABLE
status.operation.remote.CAV
B2-B10 Not used
B11 status.operation.remote.PROMPTS_ENABLED
status.operation.remote.PRMPT
B12-B15 Not used
As an example, to set bit B1 of the operation status remote summary enable register, set
status.operation.remote.enable = status.operation.remote.CAV.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
To set more than one bit of the register, set operationRegister to the sum of their decimal weights. For
example, to set bits B1 and B11, set operationRegister to 2,050 (which is the sum of 2 + 2,048).
Example
status.operation.remote.enable =
status.operation.remote.CAV
Also see
Operation Status Registers
status.operation.*

status.operation.sweeping.*

This attribute contains the operation status sweeping summary register set.
Type TSP-Link accessible
Attribute - -
.condition (R) Yes
.enable (RW) Yes
.event (R) Yes
.ntr (RW) Yes
.ptr (RW) Yes
7-298
Enable and transition registers
(on page E-9)
(on page 7-270)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
Series 2600B System SourceMeter® Instrument Reference Manual
(on page E-19). The individual bits of this register are defined in
Description
Not applicable.
Set bit indicates there is a command
available in the execution queue.
Bit B1 decimal value: 2
Binary value: 0000 0000 0000 0010
Not applicable.
Set bit indicates command prompts are
enabled.
Bit B11 decimal value: 2,048
Binary value: 0000 0100 0000 0000
Not applicable.
Uses a constant to set the CAV bit of the
operation status remote summary enable
register.
Where saved Default value
- - - -
Not saved Not applicable
Not saved 0
Not saved 0
Not saved 0
Not saved Models 2601B/2611B/2635B:
2 (All bits set)
Models
2602B/2604B/2612B/2614B/2634B/2636B:
6 (All bits set)
Status register set contents
2600BS-901-01 Rev. B / May 2013
