Section 7: TSP command reference
As an example, to set bit B1 of the operation status digital I/O overrun enable register, set
status.operation.instrument.digio.trigger_overrun.enable =
status.operation.instrument.digio.trigger_overrun.LINE1.
In addition to the above constants, operationRegister can be set to the numeric equivalent of the bit to set.
To set more than one bit of the register, set operationRegister to the sum of their decimal weights. For
example, to set bits B1 and B10, set operationRegister to 1,026 (which is the sum of 2 + 1,024).
Bit
Binary value
Decimal
Weights
Bit
Binary value
Decimal
Weights
Example 1
operationRegister =
status.operation.instrument.digio.trigger_overrun.LINE1 +
status.operation.instrument.digio.trigger_overrun.LINE10
status.operation.instrument.digio.trigger_overrun.enable =
operationRegister
Also see
Operation Status Registers
status.operation.instrument.digio.*
status.operation.instrument.lan.*
This attribute contains the operation status LAN summary register set.
Type
TSP-Link accessible
Attribute
- -
.condition (R)
Yes
.enable (RW)
Yes
.event (R)
Yes
.ntr (RW)
Yes
.ptr (RW)
Yes
Usage
operationRegister = status.operation.instrument.lan.condition
operationRegister = status.operation.instrument.lan.enable
operationRegister = status.operation.instrument.lan.event
operationRegister = status.operation.instrument.lan.ntr
operationRegister = status.operation.instrument.lan.ptr
status.operation.instrument.lan.enable = operationRegister
status.operation.instrument.lan.ntr = operationRegister
status.operation.instrument.lan.ptr = operationRegister
operationRegister
7-278
Series 2600B System SourceMeter® Instrument Reference Manual
B7
B6
B5
0/1
0/1
0/1
128
64
32
7
6
5
(2
)
(2
)
(2
)
B15
B14
B13
0/1
0/1
0/1
32,768
16,384
8,192
15
14
13
(2
)
(2
)
(2
)
(on page E-9)
(on page 7-275)
Affected by
- -
Not applicable
Status reset
Status reset
Status reset
Status reset
The status of the operation status LAN summary register; a zero (0) indicates no
bits set (also send 0 to clear all bits); other values indicate various bit settings
B4
B3
B2
0/1
0/1
0/1
16
8
4
4
3
2
(2
)
(2
)
(2
B12
B11
B10
0/1
0/1
0/1
4,096
2,048
1,024
12
11
10
(2
)
(2
)
(2
Where saved
Default value
- -
- -
Not saved
Not applicable
Not saved
0
Not saved
0
Not saved
0
Not saved
1027 (All bits set)
2600BS-901-01 Rev. B / May 2013
B1
B0
0/1
0/1
2
1
1
0
)
(2
)
(2
)
B9
B8
0/1
0/1
512
256
9
8
)
(2
)
(2
)
Uses constants to set bit
B1 and bit B10 of the
operation status digital
I/O overrun enable
register.
