Series 2600B System SourceMeter® Instrument Reference Manual

smuX.trigger.arm.set()

This function sets the arm event detector to the detected state.
Type TSP-Link accessible
Function Yes
Usage
smuX.trigger.arm.set()
X
Details
The SMU will automatically clear all the event detectors when the smuX.trigger.initiate() function is
executed. This function should be called after the sweep is initiated.
A common example of when this function can be used is when you want the SMU to immediately perform an
action the first time through the trigger model even if a programmed trigger event does not occur.
This function can also be used to start actions on the SMU in case of a missed trigger event.
Example
smua.trigger.arm.set()
Also see
smuX.trigger.initiate()
smuX.trigger.measure.set()
smuX.trigger.source.set()

smuX.trigger.arm.stimulus

This attribute selects the event that will cause the arm event detector to enter the detected state.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
eventID = smuX.trigger.arm.stimulus
smuX.trigger.arm.stimulus = eventID
eventID
X
2600BS-901-01 Rev. B / May 2013
Affected by
Source-measure unit (SMU) channel (for example, smua.trigger.arm.set()
applies to SMU channel A)
(on page 7-240)
(on page 7-241)
(on page 7-251)
Affected by
SMU reset
Instrument reset
Recall setup
Event that triggers the arm detector
Source-measure unit (SMU) channel (for example,
smua.trigger.arm.stimulus applies to SMU channel A)
Section 7: TSP command reference
Where saved Default value
Sets the arm event detector to the
detected state for SMU channel A.
Where saved Default value
Not saved 0
7-233
