Smux.trigger.endpulse.set(); Smux.trigger.endpulse.stimulus - Keithley 2601B Reference Manual

Series 2600B System SourceMeter® Instrument Reference Manual
Example
smua.trigger.endpulse.action =
smua.SOURCE_IDLE
smua.trigger.endpulse.stimulus =
trigger.timer[1].EVENT_ID
Also see
Triggering

smuX.trigger.endpulse.set()

This function sets the end pulse event detector to the detected state.
Type TSP-Link accessible
Function Yes
Usage
smuX.trigger.endpulse.set()
X
Details
This function sets the end pulse event detector to the detected state.
The SMU automatically clears all the event detectors when the smuX.trigger.initiate() function is
executed. Therefore, smuX.trigger.endpulse.set() should be called after the sweep is initiated. If the
event detectors are configured to clear automatically because the smuX.trigger.autoclear attribute is set to
smuX.ENABLE, make sure that smuX.trigger.endpulse.set() is issued after the SMU has entered the
trigger layer.
Also see
smuX.trigger.autoclear
smuX.trigger.initiate()
Triggering

smuX.trigger.endpulse.stimulus

This attribute defines which event will cause the end pulse event detector to enter the detected state.
Type TSP-Link accessible
Attribute (RW) Yes
Usage
eventID = smuX.trigger.endpulse.stimulus
smuX.trigger.endpulse.stimulus = eventID
eventID
X
2600BS-901-01 Rev. B / May 2013
(on page 3-32)
Affected by
Source-measure unit (SMU) channel (for example,
smua.trigger.endpulse.set() applies to SMU channel A)
(on page 7-235)
(on page 7-240)
(on page 3-32)
Affected by
SMU reset
Instrument reset
Recall setup
Set to the event that triggers the end pulse action of the source
Source-measure unit (SMU) channel (for example,
smua.trigger.endpulse.stimulus applies to SMU channel A)
Section 7: TSP command reference
Configure the end pulse action to achieve a
pulse and configure trigger timer 1 to control
the end of pulse.
Where saved Default value
Where saved Default value
Not saved 0
7-237
