Section 7: TSP command reference
Usage
sourceAutorange = smuX.source.autorangeY
smuX.source.autorangeY = sourceAutorange
sourceAutorange
X
Y
Details
This attribute indicates the source autorange state. Its value will be smuX.AUTORANGE_OFF when the SMU
source circuit is on a fixed range and smuX.AUTORANGE_ON when it is in autorange mode.
Setting this attribute to smuX.AUTORANGE_OFF puts the SMU on a fixed source range. The fixed range used will
be the present SMU source circuit range.
Setting this attribute to smuX.AUTORANGE_ON puts the SMU source circuit into autorange mode. If the source
output is on, the SMU will immediately change range to the range most appropriate for the value being sourced if
that range is different from the present SMU range.
Autorange will disable if the source level is edited from the front panel. Setting the source range turns off
autorange when set by using the smuX.source.rangeY attribute as well.
Resetting the instrument selects the smuX.AUTORANGE_ON.
Example
smua.source.autorangev = smua.AUTORANGE_ON
Also see
smuX.measure.autorangeY
smuX.source.rangeY

smuX.source.calibrateY()

This function generates and activates new source calibration constants.
Type TSP-Link accessible
Function Yes
Usage
smuX.source.calibrateY(range, cp1Expected, cp1Reference, cp2Expected, cp2Reference)
X
Y
range
cp1Expected
cp1Reference
cp2Expected
cp2Reference
7-218
Series 2600B System SourceMeter® Instrument Reference Manual
The state of the source autorange control. Set to one of the following:
0 or smuX.AUTORANGE_OFF: Disables source autorange
1 or smuX.AUTORANGE_ON: Enables source autorange
Source-measure unit (SMU) channel (for example, smua.source.autorangev
applies to SMU channel A)
SMU source function (v = voltage, i = current)
(on page 7-198)
(on page 7-230)
Affected by
Source-measure unit (SMU) channel (for example, smua.source.calibratev()
applies to SMU channel A)
SMU source function (v = voltage, i = current)
The measurement range to calibrate
The source value set for calibration point 1
The reference measurement for calibration point 1 as measured externally
The source value set for calibration point 2
The reference measurement for calibration point 2 as measured externally
Enables volts source autorange for
SMU channel A.
Where saved Default value
