State Description
fault The controller cannot receive power from its own inlet because of a
power failure on the inlet or a broken power supply. Instead it is
receiving power from another PRO4X PDU.
See Power-Sharing Restrictions and Connection
After entering the fault state, this sensor is listed in the Alerted Sensors
section of the Dashboard. .
unavailable The communication with the power supply sensor is lost.

Inlet

You can view all inlet information, configure inlet-related settings, or reset the inlet active energy and
min/max sensor values on the Inlet page. To open this page, click 'Inlet' in the Menu.
Inlet thresholds help you identify when your inlet enters warning or critical level. In addition, you can
automatically generate alert notifications for any warning or critical status. See
(on page 266).
Note: For multi-inlet models, see
▶
Overview:
• •
Inlet power overview, which is the same as
▶
Dip/Swell Events:
Dip/swell Events provides monitoring for short-term under-voltage events, also known as "Dips", and
short-term over-voltage events, also known as "Swells".
After configuring the thresholds for dips and swells, a waveform is captured when an event meets the
thresholds.
130
(on page 29).
Configuring a Multi-Inlet Model
Dashboard - Inlet I1
Event Rules and Actions
(on page 135).
(on page 113).
