Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Push out sensor readings' from the Action list.
3) Select a server or host which receives the data in the Destination field.
• • If the desired destination is not available yet, go to the Data Push page to specify it.
Record Snapshots to Webcam Storage
This option allows you to define an action that starts or stops a specific webcam from taking snapshots.
Per default the snapshots are stored on the PRO4X. It is recommended to specify a remote server to
store as many snapshots as possible.
▶
Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Record snapshots to webcam storage' from the Action list.
3) Select a webcam in the Webcam field.
4) Select the action to perform - 'Start recording' or 'Stop recording.'
If 'Start recording' is selected, adjust the values of the following:
• Number of snapshots - the number of snapshots to be taken when the event occurs. •
The maximum amount of snapshots that can be stored on the PRO4X is 10. If you set it
for a number greater than 10 and the storage location is on the PRO4X, after the 10th
snapshot is taken and stored, the oldest snapshots are overwritten. Storing snapshots on a
remote server does not have such a limitation.
• • Time before first snapshot - the amount of time in seconds between when the event is triggered
and the webcam begins taking snapshots.
• • Time between snapshots - the amount of time in seconds between when each snapshot is taken.
• Folder - names of the folders that will be automatically created to store webcam snapshots after •
the recording action is triggered by the rule you will configure.
Note that the Folder field is available only when the selected webcam has been configured
to store its snapshots on an "FTP" server.
Folder name
options
Serial number /
Webcam name
Serial number /
Webcam name / Rule
name
296
Definition
Two folders will be created.
• •
The parent folder's name is the serial number of PRO4X.
• •
The subfolder's name is the selected webcam's name.
Three folders will be created.
• •
Definitions of the parent folder and first subfolder are the same as the first row.
• • The final subfolder's name is the name of event rule that triggers this recording action.
.
.
