To power on a monitored device:
1) Select the IT device that you want to turn on.
2) Click Power Up.
3) Confirm the operation when prompted.
4) Observe the Power Control status of the monitored device to make sure the power-on operation
succeeds.
Editing or Deleting Ping Monitoring Settings
You can edit the ping monitoring settings of any IT device or simply delete it if no longer needed.
▶
To modify or delete any monitored IT device:
1) Choose Device Settings > Server Reachability.
2) Click the desired one in the list.
3) Perform the desired action.
• • To modify settings, make necessary changes and then click Save. To delete it, click
on the top-right corner.
Example: Ping Monitoring and SNMP Notifications
In this illustration, it is assumed that a significant PDU (IP address: 192.168.84.95) shall be monitored by
your PRO4X to make sure that PDU is properly operating all the time, and the PRO4X must send out
SNMP notifications (trap or inform) if that PDU is declared unreachable due to power or network
failure. The prerequisite for this example is that the power sources are different between your PRO4X
and the monitored PDU.
This requires the following two steps.
▶
Step 1: Set up the ping monitoring for the target PDU
1) Choose Device Settings > Server Reachability.
2) Click
3) Ensure the "Enable ping monitoring for this server" checkbox is selected.
4) Enter the data shown below.
• • Enter the server's data.
Field
IP address/hostname
• To make the PRO4X declare the accessibility of the monitored PDU every 15 seconds (3 pings * 5 •
seconds) when that PDU is accessible, enter the following data.
Field
Number of successful pings to enable feature
330
.
Data entered
192.168.84.95
Data entered
3
