When a user scans a smart card with the card reader, the card's type and ID are retrieved and shown in
the corresponding Card Type and Card ID column. If no data is shown in the two columns, it means the
scanned card may not be supported by the card reader.
Tip: You can use a third-party application, such as Power IQ, to retrieve the card's data to perform
security features like cabinet access control. Refer to that application's user documentation for more
information.
▶
Door handle-integrated card readers:
• •
This type of card reader is integrated in the door handle, which is any series below:
• Emka Agent E •
• SouthCo H3-EM •
• Dirak eLine MLR 2500 •
Note: Not every SouthCo H3‑EM door handle has a card reader integrated.
• •
It is connected via the DX2‑DH2C2 module.
• • The Channel column indicates which door handle port (channel) it is connected to.
• •
Note that the serial number displayed for this card reader is the same as DX2‑DH2C2's serial
number.
Each DX2‑DH2C2 module can show two card readers because they have two ports for
connecting two door handles with card readers integrated.
▶
Standalone USB card readers:
• •
It is directly connected to PRO4X.
• •
The Channel column does not show any data.
