Sensor type
residualCurrent
residualDCCurrent
Note: For information on RCM Type A and B sensors, see RCM Current Sensor.

Inlet Pole Sensor Threshold Information

This command is only available for a three-phase PDU except for an in‑line monitor (PX3-3000 series).
This command syntax shows the specified inlet pole sensor's threshold-related information.
# show sensor inletpole <n> <p> <sensor type>
To show detailed information, add the parameter "details" to the end of the command.
# show sensor inletpole <n> <p> <sensor type> details
Variables:
• •
<n> is the number of the inlet whose pole sensors you want to query. For a single-inlet PDU, <n> is
always 1.
• • <p> is the label of the inlet pole whose sensors you want to query.
Pole Label
<p>
1 L1
2 L2
3 L3
• •
<sensor type> is one of the following sensor types:
Sensor type
current
voltage
400
Description
RCM current sensor
• • For Type A, it is the sensor that detects residual
AC current.
• •
For Type B, it is the sensor that detects both
residual AC and DC current.
RCM DC current sensor - detects residual DC current
only.
Available only on PDUs with RCM Type B.
Current sensor
L1
L2
L3
Description
Current sensor
Voltage sensor
•
Voltage sensor
L1 - L2
L2 - L3
L3 - L1
