Description
Cascading status, which can be one of the following:
No Cascading: This device's cascading mode is set to None.
Network Bridge Enabled: This device's cascading mode is set to Bridging. Its IP address is
also displayed on this page.
Port Forwarding Primary: This device's cascading mode is set to Port Forwarding, and it
is a primary device.
Expansion unit Connected: Indicates whether the presence of a expansion unit
device is detected - yes or no.
Port Forwarding Expansion unit: This device's cascading mode is set to Port Forwarding,
and it is a expansion unit device.
Expansion unit Connected: Indicates whether the presence of a expansion unit
device is detected - yes or no.
Cascade Position: Indicates the position of a expansion unit device in the Port
Forwarding mode. 1 represents Expansion unit 1, 2 represents Expansion unit
2, and so on.
A port forwarding expansion unit device will also display the primary device's
IP address on this page.
1) Press
to show the Ethernet pages.
There can be one or two pages: ETH1 and ETH2.
93
