To download a backup file:
You must have the Administrator Privileges or "Unrestricted View Privileges" to download a backup file.
1) Choose Maintenance > Backup/Restore.
2) Check the 'Backup format' field. If the chosen value does not match your need, change it.
Option Description
• •
Partial content is base64 encoded.
Encrypted
• •
Its content is encrypted using the AES-128 encryption algorithm.
• •
The file is saved to the TXT format
• •
Content is displayed in clear text.
Cleartext
• •
The file is saved to the TXT format.
1) Click Download Device Settings. Save the file onto your computer.
▶
To restore using a backup file:
You must have the Administrator Privileges to restore the device settings.
1) Choose Maintenance > Backup/Restore.
2) Click Browse to select the backup file.
3) Click 'Upload & Restore Device Settings' to upload the file.
• • A message appears, prompting you to confirm the operation and enter an administrator password.
4) Enter the password, then click Restore.
5) Wait until the PRO4X resets and the Login page re-appears, indicating that the restore is complete.

Network Diagnostics

PRO4X provides the following tools in the web interface for diagnosing potential networking issues.
• •
Ping: The tool is useful for checking whether a host is accessible through the network or Internet.
• • Trace Route: The tool lets you find out the route over the network between two hosts or systems.
• •
List TCP Connections: You can use this function to display a list of TCP connections.
Tip: These network diagnostic tools are also available through the CLI.
Choose Maintenance > Network Diagnostics, and then perform any function below.
▶
Ping:
1) Type values in the following fields.
351
