Changing the Sensor Name
This command names an environmental sensor.
config:# externalsensor <n> name "<name>"
Variables:
• •
<n> is the ID number of the environmental sensor that you want to configure. The ID number is
available in the web interface or using the command "show externalsensors <n>" in the
CLI. It is an integer starting at 1.
• •
<name> is a string comprising up to 64 ASCII printable characters. The <name> variable must be
enclosed in quotes when it contains spaces.
Specifying the CC Sensor Type
Raritan's contact closure sensor supports the connection of diverse third-party. You must specify the
type of connected detector/switch for proper operation. Use this command when you need to specify
the sensor type.
config:# externalsensor <n> sensorSubType <sensor_type>
Variables:
• •
<n> is the ID number of the environmental sensor that you want to configure. The ID number is
available in the PRO4X web interface or using the command "show externalsensors <n>" in
the CLI. It is an integer starting at 1.
• •
<sensor_type> is one of these types: contact, smokeDetection, waterDetection or vibration.
Type
contact
smokeDetection The connected detector/switch is for detection of the smoke
waterDetection The connected detector/switch is for detection of the water
vibration
Setting the X Coordinate
This command specifies the X coordinate of an environmental sensor.
config:# externalsensor <n> xlabel "<coordinate>"
498
Description
The connected detector/switch is for detection of door lock or
door closed/open status.
presence.
presence.
The connected detector/switch is for detection of the vibration.
