RMS current (A) and rated current
• • The smaller, gray text adjacent to RMS current is the rated current.
• •
A bar showing the RMS current level
• •
RMS voltage (V)
The RMS current bars automatically change colors to indicate the current status according to your
configured thresholds. To configure thresholds, see Inlet.
Status
normal
above upper warning
above upper critical

Dashboard - OCP

Availability and total number of OCPs depend on the models.
▶
Each OCP's link:
To view more information or configure individual OCPs, click the desired OCP's index number, which is
either BR1, BR2, and so on; or C1, C2 and so on, to go to its setup page.
Bar colors
