LEGRAND Server Technology PRO4X User Manual page 401

Sensor type
activePower
apparentPower
powerFactor
activeEnergy
Displayed information:
• •
Without the parameter "details," only the reading, state, threshold, deassertion hysteresis and
assertion timeout settings of the specified inlet pole sensor are displayed.
• •
With the parameter "details," more sensor information is displayed, including resolution and range.
• •
If the requested sensor type is not supported, the "Sensor is not available" message is displayed.
▶
Additional sensors supported by specific models:
Specific PRO4X models support some or all of the following sensors. The CLI command(s) listed above
can be also applied to the following sensors. Note that the measurement unit of current values in CLI is
A, not mA.
Sensor type
peakCurrent
reactivePower
displacementPowerFactor Displacement power factor sensor
residualCurrent
residualDCCurrent
Note: For information on RCM Type A and B sensors, see RCM Current Sensor.
Description
Active power sensor
Apparent power sensor
Power factor sensor
Active energy sensor
Description
Peak current sensor
Reactive power sensor
RCM current sensor
• • For Type A, it is the sensor that detects residual
AC current.
• • For Type B, it is the sensor that detects both
residual AC and DC current.
RCM DC current sensor - detects residual DC current
only.
Available only on PDUs with RCM Type B.
Supported on PXC and Legrand
PDU only
• •
three-phase models also
support pole-level peak
current
• •
models with metered
breakers also support
breaker-level peak current
•
