Field
*Trip cause outlet
handling
1) Click Save.
▶
To reset ALL energy counters:
An energy reading is a value of total accumulated energy, which is never reset, even if the power fails or
the PRO4X is rebooted. However, you can manually reset this reading to restart the energy
accumulation process. Only users with the "Admin" role assigned can reset energy readings.
Note: This reset button does not reset the energy values of outlet groups. Go to the Outlet Groups page
to reset that value.
1) On the PDU page, in the Settings section, make sure Edit Settings is not clicked, or cancel out of
editing settings.
2) On the Reset all energy counters option, click Reset, then click on the confirmation message.
• All energy readings are reset to zero. •
Tip: You can also reset the energy reading of an individual inlet or outlet on those pages.
▶
To reset all minimum/maximum values:
For readings that record a maximum and minimum numeric value, you can reset these values as needed
to clear the previous highs and lows.
1) On the PDU page, in the Settings section, make sure Edit Settings is not clicked, or cancel out of
editing settings.
2) On the Reset all minimum/maximum values option, click Reset, then click on the confirmation
message.
• • All previously recorded maximum and minimum values are reset.
▶
To view total energy and power on multi-inlet models:
For multi-inlet models or in‑line monitors, a "Sensors" section show the data of total active energy and
total active power."PDU Total" also gives the sum of active power and active energy and it is displayed
on the Dashboard.Dashboard - PDUs
124
Function
If an outlet is suspected to have caused an
OCP trip event, it can optionally be marked
as "Suspended" and handled differently.
• •
Options: Keep outlet state unchanged,
or Suspend Outlet
(on page 112)
Note
Suspended outlets are not turned back on when the
OCP is closed.
See Trip Cause Outlet Handling
Not supported on PX2, PXE, and PXO.
(on page 127).
