Event types Radio buttons
• •
Connected: action occurs only when the selected device is
Device connection
physically connected to it.
or disconnection,
such as a
• • Disconnected: action occurs only when the selected device
USB‑cascaded
is physically disconnected from it.
device
• • Both: action occurs both when the selected device is
physically connected to it and when it is disconnected.
+12V Supply 1 Available radio buttons include "Fault," "OK" and "Both."
Status
• •
Fault: action occurs only when the selected 12V power
supply to the controller enters the fault state.
• • OK: action occurs only when the selected 12V power supply
to the controller enters the OK state.
• • Both: action occurs whenever the selected 12 power
supply's status changes.
Xerus Default Log Messages for All Products
Listed here are all default messages for all Xerus events, including all supported products. Not all
products support all events, and events are marked here with the supported model type.
Event/context Default message on event assertion
Asset Management >
Blade extension overflow occurred on strip
Blade Extension
[AMSNUMBER] ('[AMSNAME]').
Overflow
Asset Management >
Composition changed on composite asset
Composite Asset Strip
strip [AMSNUMBER] ('[AMSNAME]').
Composition Changed
Config parameter '[CONFIGPARAM]' of asset
Asset Management >
strip [AMSNUMBER] ('[AMSNAME]') changed
Device Config Changed
to '[CONFIGVALUE]' by user '[USERNAME]'.
Firmware update for asset strip
Asset Management >
[AMSNUMBER] ('[AMSNAME]'): status
Firmware Update
changed to '[AMSSTATE]'.
Blade extension with ID '[AMSTAGID]'
Asset Management >
connected at rack unit
Rack Unit > Blade
[AMSRACKUNITPOSITION] of asset strip
Extension Connected
[AMSNUMBER] ('[AMSNAME]').
Asset tag with ID '[AMSTAGID]' connected at
Asset Management >
rack unit [AMSRACKUNITPOSITION], slot
Rack Unit > Tag
[AMSBLADESLOTPOSITION] of asset strip
Connected
[AMSNUMBER] ('[AMSNAME]').
Default message on event
deassetion
Blade extension overflow cleared for
strip [AMSNUMBER] ('[AMSNAME]').
Blade extension with ID
'[AMSTAGID]' disconnected at rack
unit [AMSRACKUNITPOSITION] of
asset strip [AMSNUMBER]
('[AMSNAME]').
Asset tag with ID '[AMSTAGID]'
disconnected at rack unit
[AMSRACKUNITPOSITION], slot
[AMSBLADESLOTPOSITION] of asset
strip [AMSNUMBER] ('[AMSNAME]').
Model
Type
