6) In this example, 'Above upper critical threshold' is selected because we want the PRO4X to react
only when the selected temperature sensor's reading enters the upper critical range. A "Trigger
condition" field appears, requiring you to define the "exact" condition related to the "upper critical"
event.
7) Select the desired radio button to finish the event configuration. Refer to the following table for
different types of radio buttons.
• • See Sample Event Rules
8) Add and/or remove actions to configure the rule. Select actions from the 'Available actions' list to
create the Select actions list.
▶
Radio buttons for different events:
Some events require you to configure the "Trigger condition".
Event types Radio buttons
• •
Numeric sensor
threshold-crossing
events, or the
occurrence of the
• •
selected event --
true or false
• •
• •
State sensor state
change
• •
• •
(on page 313).
Asserted: action occurs only when the selected event
occurs. That is, the status of the event transits from FALSE
to TRUE.
Deasserted: action occurs only when the selected event
disappears or stops. That is, the status of the selected event
transits from TRUE to FALSE.
Both: action occurs both when the event occurs (asserts)
and when the event stops/disappears (deasserts).
Alarmed/Open/On: action occurs only when the chosen
sensor enters the alarmed, open or on state.
No longer alarmed/Closed/Off: action occurs only when the
chosen sensor returns to the normal, closed, or off state.
Both: action occurs whenever the chosen sensor switches
its state.
