To send SNMP v3 notifications:
1) In the 'Notification type' field, select 'SNMPv3 trap' or 'SNMPv3 inform.'
2) For SNMP TRAPs, the engine ID is prepopulated.
3) For SNMP INFORM communications, leave the resend settings at their default or do the following:
a. In the Timeout field, specify the interval of time, in seconds, after which a new inform a.
communication is resent if the first is not received. For example, resend a new inform
communication once every 3 seconds.
b. In the 'Number of retries' field, specify the number of times you want to re‑send the inform b.
communication if it fails. For example, inform communications are re‑sent up to 5 times when
the initial communication fails.
4) For both SNMP TRAPS and INFORMS, enter the following as needed and then click OK to apply the
settings:
a. a. Host name
b. b. Port number
c. User ID for accessing the host -- make sure the User ID has the SNMPv3 permission. c.
d. d. Select the host security level
Security level
"noAuthNoPriv" Select this if no authorization or privacy protocols are
"authNoPriv"
"authPriv"
Start or Stop a Lua Script
If you have created or loaded a Lua script file into the PRO4X, you can have that script automatically run
or stop in response to a specific event.
See Lua Scripts (on page 334).
302
Description
needed.
Select this if authorization is required but no privacy
protocols are required.
• •
Select the authentication protocol - MD5 or SHA
• •
Enter the authentication passphrase and then confirm
the authentication passphrase
Select this if authentication and privacy protocols are
required.
• •
Select the authentication protocol - MD5 or SHA
• • Enter the authentication passphrase and confirm the
authentication passphrase
• •
Select the Privacy Protocol - DES or AES
• • Enter the privacy passphrase and then confirm the
privacy passphrase
