Option Description
A numeric Sets a value for the specified threshold of the specified inlet
value pole sensor and enables this threshold at the same time.
• •
<hy_value> is a numeric value that is assigned to the hysteresis for the specified inlet pole sensor.
• •
<as_value> is a number in samples that is assigned to the assertion timeout for the specified inlet
pole sensor.
▶
Additional sensors supported by specific models:
Specific models support some or all of the following sensors. The CLI command(s) listed above can be
also applied to the following sensors. Note that the measurement unit of current values in CLI is A, not
mA.
Sensor type
peakCurrent
reactivePower
displacementPowerFactor Displacement power factor sensor
residualCurrent
residualDCCurrent
Commands for Overcurrent Protector Sensors
A sensor configuration command for overcurrent protectors begins with sensor ocp.
You can configure various overcurrent protector threshold settings at a time by combining multiple
commands.
Description
Peak current sensor
Reactive power sensor
RCM current sensor
• • For Type A, it is the sensor that detects residual AC
current.
• • For Type B, it is the sensor that detects both
residual AC and DC current.
RCM DC current sensor - detects residual DC current
only.
Available only on PDUs with RCM Type B.
Supported on PXC and Legrand
PDU only
• •
three-phase models also
support pole-level peak
current
• •
models with metered
breakers also support
breaker-level peak current
