Field Description
Timeout The interval of time, in seconds, after which a new inform
communication is resent if the first is not received.
• •
For example, resend a new inform communication once every 3
seconds.
Number of The number of times you want to resend the inform communication if
retries it fails.
• •
For example, inform communications are resent up to 5 times
when the initial communication fails.
Host The IP address of the device(s) you want to access. This is the address
to which notifications are sent by the SNMP agent.
You can specify up to 3 SNMP destinations.
Port The port number used to access the device(s).
Community The SNMP community string to access the device(s). The community
is the group representing the PRO4X and all SNMP management
stations.
1) Click Save.

Downloading SNMP MIB

You must download an appropriate SNMP MIB file for successful SNMP communications. Always use the
latest SNMP MIB downloaded from the current firmware of your PRO4X.
You can download the MIBs from two different pages of the web interface.
▶
MIB download via the SNMP page:
1) Choose Device Settings > Network Services > SNMP.
2) Click the Download MIBs title bar.
3) Select the desired MIB file to download.
• PDU2-MIB: The SNMP MIB file for PRO4X management. •
• • ASSETMANAGEMENT-MIB: The SNMP MIB file for asset management.
4) Click Save to save the file onto your computer.
375
