LEGRAND Server Technology PRO4X User Manual page 319

By default, data logging is enabled. You must have the "Administrator Privileges" or "Change Pdu, Inlet,
Outlet & Overcurrent Protector Configuration" permissions to change the setting.
Important: The third-party management solutions like PowerIQ rely on the data logging feature, and the
settings should be changed only in accordance with those systems' requirements.
▶
To configure the data logging feature:
1) Choose Device Settings > Data Logging.
2) To enable the data logging feature, select the "Enable" checkbox in the General Settings section.
3) Measurements Per Log Entry: Valid range is from 1 to 600. The default is 60.
4) Log capacity: Valid range varies, from 60 to 20,000.
5) Enable data log backup: Select this checkbox to enable an automatic USB backup of your data log.
USB stick with specially configured file required, see procedure below.
6) Verify that all sensor logging is enabled. If not, click Enable All at the bottom of the page to have all
sensors selected.
7) Click Save.
319
