Field Description
LED Color
This field is configurable only after the Operation Mode is set
to Manual Override.
Determine what LED color is shown for this rack unit if the LED is lit.
▶
To expand a blade extension strip:
A blade extension strip, like an asset strip, has multiple tag ports. An extension strip is marked with a
grayer color on the Asset Strip page, and its tag ports list is collapsed by default.
Note: If you need to temporarily disconnect the blade extension strip from the asset strip, wait at least
1 second before re-connecting it back, or the PRO4X device may not detect it.
1) Locate the rack unit (tag port) where the blade extension strip is connected. Click its slot number,
whose format is similar to
2) All tag ports of the blade extension strip are listed below it. Their port numbers are displayed in the
Slot column.
190
, where N is the total number of its tag ports.
