Variables:
• •
<ETH> is one of the options -- eth1 or eth2.
Option
eth1
eth2
• •
<option> is one of the options: auto, 10Mbps, 100Mbps or 1000Mbps.
Option Description
auto System determines the optimum LAN speed through auto-negotiation.
10Mbps The LAN speed is always 10 Mbps.
100Mbps The LAN speed is always 100 Mbps.
1000Mbps The LAN speed is always 1000 Mbps.
Changing the LAN Duplex Mode
This command determines the LAN interface duplex mode.
config:#
Variables:
• •
<ETH> is one of the options -- eth1 or eth2.
Option
eth1
eth2
• •
<mode> is one of the modes: auto, half or full.
Option Description
auto The PRO4X selects the optimum transmission mode through auto-
negotiation.
half Half duplex:
Data is transmitted in one direction (to or from the PRO4X) at a time.
428
Description
ETH1 port
ETH2 port
network ethernet <ETH> duplexMode <mode>
Description
ETH1 port
ETH2 port
