To check the server monitoring states and results:
1) The column labeled "Ping Enabled" indicates whether the monitoring for the corresponding IT
device is activated or not.
2) The column labeled "Status" indicates the accessibility of monitored equipment.
Status
Reachable
Unreachable
Waiting for reliable
connection
3) If your model supports outlet switching, one more column displays -- Power Control.
Power control Description
status
(disabled) Power control is not enabled for the monitored equipment.
Server power is The outlet or outlet group associated with the monitored
on equipment is being powered on.
• •
Server power is The outlet or all outlets of the outlet group associated with the
off monitored equipment are being powered off.
Server is shutting The shutdown command was sent to the monitored equipment,
down but the shutdown operation has not completed or succeeded yet.
Power state Cannot determine the power state of the outlet(s) associated
unknown with the monitored device.
For example, maybe the outlet group associated with the
monitored device has been deleted.
▶
To shut down a monitored device:
1) Select the IT device that you want to shut down.
2) Click Shutdown.
3) Confirm the operation when prompted.
4) Observe the Power Control status of the monitored device to make sure the shutdown operation
succeeds.
Description
The monitored equipment is accessible.
The monitored equipment is inaccessible.
The connection between the device and the monitored
equipment is not reliably established yet.
In the scenario where an 'outlet group' is associated with the
equipment, the message 'Server power is on' is shown as long
as one of the outlets in the outlet group remains powered on.
