Outlets
With the front panel display, you can:
• •
Show each outlet's information.
• •
Turn on, off or power cycle an individual outlet on models that support switching. Front panel outlet
control must be enabled in the Front Panel Settings.
Multiple outlet information can be shown on the display. Check the bottom of the display for control
buttons and their actions.
▶
To show an outlet's information:
1) Select "Outlets" in the Main Menu, and press
2) The list of outlets is shown with their receptacle types, current values (A), and power states which
are indicated by the colors of circles.
The currently-selected outlet number and total of outlets are indicated in the top-right corner of
the display.
• • A green circle indicates that this outlet is powered on.
• • A gray circle indicates that this outlet is powered off.
If so, the word "Off" replaces the current value.
.
