Change the priority of the specified server:
config:# authentication radius modify <server_num> sortPositon <position>
Tip: You can add more than one parameters to the command. For example, "authentication
radius modify <server_num> host <host> authType <rds_type> authPort
<auth_port> accountPort <acct_port> ...".
Variables:
• •
<server_num> is the sequential number of the specified server in the Radius server list.
• •
<host> is the new IP address or host name of the Radius server.
• •
<rds_type> is one of the Radius authentication types: pap, chap, msChapV2.
• • <auth_port> is the new authentication port number.
• •
<acct_port> is the new accounting port number.
• •
<timeout> is the new timeout value in seconds. It ranges between 1 to 10 seconds.
• •
<retries> is the new number of retries. It ranges between 0 to 5.
▶
To enter the shared secret:
1) After executing the above Radius command, the system automatically prompts you to enter the
shared secret.
2) Type the secret and press Enter.
3) Re-type the same secret and press Enter.
▶
Example:
config:# authentication radius add 192.168.7.99 chap 1812 1813 10 3
Removing an Existing Radius Server
This command removes an existing Radius server from the server list.
config:# authentication radius delete <server_num>
Variables:
• •
<server_num> is the sequential number of the specified server in the Radius server list.

Environmental Sensor Configuration Commands

An environmental sensor configuration command begins with externalsensor. You can configure the
name and location parameters of an individual environmental sensor. Actuators are configured with
their own commands.
