Operation:
1) Choose Device Settings > Event Rules > New Action.
2) Select 'Log an event message' from the Action list.
3) Select the 'Use custom log message' checkbox, and then create a custom message in the provided
text box.
• To automatically insert message placeholders, open the Custom Log Message Help section. Search •
for placeholders and click to include them in your message.
4) Click Create.
Shut down a Server and Control its Power
The "Power control server" action is available only when your PRO4X is outlet-switching capable.
You can configure the PRO4X to shut down a specific server and then turn off its outlet(s), or turn on
that server's outlet(s) after a certain event occurs.
The server must be one of the servers being monitored by your PRO4X and the same PRO4X supplies
power to it. See Monitoring Server Accessibility
Tip: If the server has multiple power cords, make sure all of its power cords are connected to the same
PRO4X and you have created an outlet group for controlling all outlets simultaneously.
▶
Operation:
1) Choose Device Settings > Event Rules >
2) Select 'Power control server' from the Action list.
3) In the Operation field, select an action for the server.
• Power up: Turns on the outlet or outlet group associated with the selected server. •
• Graceful shutdown: Shuts down the selected server first and then turn off its associated outlet or •
outlet group.
4) Select the server you want in the Server field.
• If PRO4X cannot power control any server, a message 'Power control not configured' is shown in •
the end of the server's host name or IP address.
Push Out Sensor Readings
You can configure the PRO4X to push sensor log to a remote server after a certain event occurs,
including logs of internal sensors, environmental sensors and actuators.
If you have connected asset strips, you can also configure the PRO4X to push the data to a server.
Before creating this action, make sure that you have properly defined the destination servers and the
data to be sent on the Data Push page.
Tip: To send the data at a regular interval, schedule this action. Note that the "Asset management log" is
generated only when there are changes made to any asset strips or asset tags, such as connection or
disconnection events.
(on page 325) .
.
