Open the Peripheral Devices page by clicking Peripherals in the Menu. Then you can:
• •
Perform actions on multiple sensors/actuators by using the control/action icons on the top-right
corner.
• • Go to an individual sensor's or actuator's data/setup page by clicking its name.
▶
Sensor/actuator overview on this page:
If any sensor enters an alarmed state, it is highlighted in yellow or red. An actuator is never highlighted.
Column Description
Name By default, the name assigned contains:
• •
Sensor/actuator type, such as "Temperature" or "Dry Contact."
• •
Sequential number of the same sensor/actuator type, like 1, 2, 3
and so on.
You can customize the name. Customize names on the individual
sensor page.
Reading Numeric sensors, such as temperature and humidity, show the
reading.
State Available for all sensors and actuators.
page 175)
Type Sensor or actuator type.
Serial This is the serial number printed on the sensor package's label.
Number
Position Position indicates where this sensor or actuator is located in the
sensor chain.
Identifying the Sensor Position and Channel
Actuator Indicates whether this sensor package is an actuator or not. If yes,
the checkmark symbol
▶
To release or manage sensors/actuators:
You can multi-select sensors to release or manage them. Releasing is necessary when the maximum
number of managed sensors are in use, and you need to make a change, such as replacing old sensors
with new ones, or making space by removing an unneeded type and adding a different type. When you
manage sensors individually, you can manually select ID numbers--this allows you to simultaneously
Sensor/Actuator States
(on page 177)
is shown.
(on
