LEGRAND Server Technology PRO4X User Manual page 422

• •
<dest-1> is a combination of the IP address and subnet mask of the other subnet. The format is IP
address/subnet mask.
• •
<hop> is the IP address of the next hop router.
• •
<ETH> is one of the interfaces: ETH1/ETH2, WIRELESS and BRIDGE. Type "bridge" only when your
PRO4X is in the bridging mode.
• •
<route_ID> is the ID number of the route setting which you want to delete or modify.
• •
<dest-2> is a modified route setting that will replace the original route setting. Its format is IP
address/subnet mask. You can modify either the IP address or the subnet mask or both.
Configuring IPv6 Parameters
An IPv6 configuration command begins with network ipv6.
Setting the IPv6 Configuration Mode
This command determines the IP configuration mode.
config:# network ipv6 interface <ETH> configMethod <mode>
Variables:
• •
<ETH> is one of the network interfaces: ETH1/ETH2, WIRELESS, or BRIDGE. Note that you must
choose/configure the bridge interface if your PRO4X is set to the bridging mode.
Note: In the bridging mode, only the IP parameters of the BRIDGE interface function. The IP
parameters of ETH1/ETH2 and WIRELESS interfaces do NOT function.
Interface Description
eth1 Determine the IPv6 configuration mode of the ETH1 interface (wired
networking).
eth2 Determine the IPv6 configuration mode of the ETH2 interface (wired
networking).
wireless Determine the IPv6 configuration mode of the WIRELESS interface
(that is, wireless networking).
bridge Determine the IPv6 configuration mode of the BRIDGE interface (that
is, bridging mode).
• •
<mode> is one of the modes: automatic or static.
Mode Description
automatic*
The IPv6 configuration mode is set to automatic.
static The IPv6 configuration mode is set to static IP address.
422
