To manually capture a waveform:
1) On the Outlets page, click an outlet to go to the details page.
2) Scroll down to the Waveform section.
3) Click Update to generate the waveform.
• Hover your mouse over the waveform to view individual data points. •
Power-Off Period Options for Individual Outlets
There are two options for setting the power-off period during the power cycle on each individual
outlet's page.
Option Function
PDU defined Follows the global power-off period setting, which is set on
(configured value) the PDU page. The value in parentheses is the current global
value.
• •
Customized time

Outlet Groups

Only PDUs with outlet-switching and/or outlet-metering feature show this menu item.
Choose Outlet Groups in the Menu.
Select an existing time option, or type a new value with an
appropriate time unit added, such as s for seconds.
