LEGRAND Server Technology PRO4X User Manual page 150

2) Configure available fields. Note that the fields marked with * are only available on outlet-switching
capable models.
Field Description
Name Type an outlet name up to 64 characters long.
*State on Click this field to select this outlet's initial power state.
device
• •
Options: on, off, last known and PDU defined.
startup
• •
Note that any option other than "PDU defined" will override the
global outlet state setting on this particular outlet.
*Power off Select an option to determine how long this outlet is turned off
period before turning back on.
during
• •
Options: PDU defined or customized time. See
power cycle
Options for Individual Outlets
• •
Note that any time setting other than "PDU defined" will override
the global power-off period setting on this particular outlet.
*Non-critical Select this checkbox only when you want this outlet to turn off in the
load shedding mode. See
Deactivate
1) Click Save.
2) The outlet's custom name, if available, is displayed in the outlets list, following by its label in
parentheses.
Note for 'State on device startup': This setting works only when 'Relay behavior on power loss' is set to
Non‑latching. This is because all relays keep their states unchanged in the latching mode regardless of
the power supply status.
▶
To reset this outlet's energy counter or minimum/maximum values:
Energy counter is stored for each outlet. All outlet sensors with numeric readings store their minimum
and maximum recorded reading. You can reset these values for an individual outlet as desired. Only
users with the "Admin" role assigned can reset these readings.
1) On the individual outlet page, scroll down to Settings.
2) Click the Reset button to either "Reset energy counter" or Reset minimum/maximum.
3) Click to confirm the reset.
150
(on page 155).
Load Shedding Mode: Activate or
(on page 146).
Power-Off Period
