Tip: You can also acknowledge all alarms in the front panel display.

PDU

Generic information and PDU settings are available on the PDU page.
To open the PDU page, click 'PDU' in the Menu.
▶
Device information shown:
• •
Firmware version
• • Serial number
• •
MAC address
• •
Rating
• •
Internal Beeper State
• •
Status of Power Supply Sensor
▶
To configure global settings:
1) Click Edit Settings.
2) Now you can configure the fields.
• • For time-related fields, you can also type a value manually, making sure to type in a time unit as
shown in the drop-down list of values. For example, 30 s for seconds, 30 min for minutes, and so
on.
In the following table, those fields marked with * are available on an outlet-switching
capable model only.
Field
Name
122
Function
Customizes the device name.
Note
