• ID number of the event •
• • Date and time of the event
• • Event type
• • A description of the event
2) To filter the list, select the desired event type in the 'Filter event class' field, or enter keywords in the
'Filter by log message' field.
3) The log is refreshed automatically at a regular interval of five seconds. To avoid any new events'
interruption during data browsing, you can suspend the automatic update by clicking Pause.
• To restore automatic update, click Resume. Those new events that have not been listed yet due to •
suspension will be displayed in the log now.
▶
To clear the local log:
1) Click Clear Log on the top-right corner.
2) Click Clear Log on the confirmation message.

Updating the Firmware

When performing the firmware update, the PRO4X keeps each outlet's power status unchanged so no
server operation is interrupted. During and after the firmware update, outlets that have been powered
on prior to the update remain powered ON and outlets that have been powered off remain powered
OFF.
You must be the administrator or a user with the Firmware Update permission to update the firmware.
Before starting, read the release notes. If you have any questions or concerns, contact Technical Support
BEFORE updating.
On a multi-inlet PDU, all inlets must be connected to power for the PDU to successfully update its
firmware.
Note that firmware update via iOS mobile devices, such as iPad, requires the use of iCloud Drive or a file
manager app.
Firmware update can also be completed using methods other than the web interface. See
Configuration and Upgrade Methods
Warning: Do NOT perform the firmware update over a wireless network connection.
▶
To update the firmware:
1) Choose Maintenance > Update Firmware.
2) Click Browse to select an appropriate firmware file.
3) Click Upload. A progress bar appears to indicate the upload process.
4) Select Free memory before upload to clear up the memory.
344
(on page ).
