Available on models with outlet-metering.
To configure thresholds-related settings for multiple outlets:
1) On the Outlets page, click
2) In the "Show Outlet Sensors of Type" field, select a sensor type.
3) In the "For Outlets of Receptacle Type" field, select an outlet type.
4) Select the checkboxes of the outlets you want to configure.
5) Click the Edit Thresholds link.
6) Make changes as needed.
• To enable any threshold, select the corresponding checkbox.
• Type a new value in the accompanying text box.
7) Click Save.
Default Voltage and Current Thresholds
The following are factory-default voltage and current thresholds. There are no default values set for
lower current thresholds because lower thresholds are not useful.
Availability of diverse thresholds depends on the capability of the model you purchased.
Single-phase inlets or outlets:
RMS voltage:
Threshold
Lower critical
Lower warning
Upper warning
Upper critical
142
> Threshold Bulk Setup.
Default value
-6% of minimum rating
-3% of minimum rating
+3% of maximum rating
+6% of maximum rating
